Resonant Converter Control Loop Design for Telecommunication

Addressing the complexity of designing control systems for resonant converters applied in power supplies for amplifying TV and radio signals, this session proposes a streamlined solution. Utilizing a simulation tool like PSIM, the frequency response is obtained, then seamlessly imported into SmartCtrl for efficient and comprehensive control design. SmartCtrl automatically generates all possible stable solutions. The results encompass system performance metrics, including frequency and transient responses, along with detailed information on the compensator, power stage, and steady-state waveforms. Easily exportable for simulation in PSIM, this approach simplifies the intricate tasks of resonant converter control design in telecommunications applications.

Featuring SmartCtrl by Power Smart Control, available through the Altair Partner Alliance.
